Product Description

TYS-1300 Box stitching machine adopts lead edge lifing platform feeding mechanism which requires by one worker to carry out stitching of double piece boxes to reduce labor intensity and improve working efficiency.

stitching-machine

TYS-1300 box stitching machine Advantages:

1. Adopts Japan double servo system.

2. Stapling head, punching and sliding are all adopts Japan alloy steel DC53 by strict heat process to ensure durable.

3. Suit for 3/5 ply offset carton and cover or no cover was stitched.

4. Single nail, double nail, strengthen nail can be stitched one time.

5. Size was controlled by electric fault was showed on the screen.

6. Stitching distance 30-100mm can be adjusted as requested.

contact

Specificattons

Max. paper size(A+B)x2:
Min.paper size(A+B)x2:
Max. paper length. A:
Min.paper length. A:
Max. paper width. B:
Min.paper width. B:
Min.paper height(C+D+C):
Stitching range:
No of stitching:
Machine speed:
Power:
Machine length:
Machine width:
Total weight:

2600mm
1060mm
1150mm
350mm
650mm
180mm
400mm
30-100mm
1-99
500s/m
12HP
2500mm
2600mm
3300kg
